Four Bands Mobile Phone Signal Jammer 100m Shielding Range High Integration

Name: Four Bands Mobile Phone Signal Jammer 100m Shielding Range High Integration
Brand: wolvesteam
Price: 1 USD

Buy cheap Four Bands Mobile Phone Signal Jammer 100m Shielding Range High Integration product

Brand Name : wolvesteam

Model Number : JM110826

Certification : CE

Place of Origin : China

MOQ : 1

Price : negotiated price

Payment Terms : L/C, T/T

Supply Ability : 100pieces/montgh

Delivery Time : 20 days

Packaging Details : Box , 37.5*18*8.5 cm

Output power : 45Watt (Four bands)

Jamming Range : Up to 100 meters (Depends on the signal strength at the application place.)

Cooling system : Active "smart" with integrated incoming air filter

Automatic switching power supply : ~230VAC / ~110VAC +24VDC

Operating temperature : -10°C ~ +60°C

Humidity : Up to 80%

Antenna : 7dBi high gain directional antenna

Contact Now

45W High Power indoor Cell phone Jammer up to 100m Shielding Range CDMA GSM 3G blocker

Product Description

Technique characteristics

· Taking use of super-high frequency with high effective power.

· Effective output power (channel power) and bigger interfere radius.

· Only interfere downlink frequency of mobile system,without disturb normally working of Base Stations.

· Imported elements: Slow start up design of circuit. These elements can maintain the stable operation condition with high integration.

Technical Specifications

Four frequency bands:

Output Interface Output Frequency

CH1 CDMA: 850-960MHz

CH2 DCS: 1805-1880MHz

CH3 PCS: 1920-1990MHz

CH4 3G: 2110-2170MHz

Output power: 45Watt (Four bands)

Power supply: ~230VAC / ~110VAC +24VDC

Antennae type choice: 7dBi high gain directional antenna

Housing: Metal enclosure

Operation temperatures: -10° … +50° C

Cooling system: Active "smart" with integrated incoming air filter

Size of Main Frame: 37.5*18*8.5 cm

Total systems weight: 14KG/set

Humidity: Up to 80%

Shielding Range: Up to 100 meters

Certification: CE, FCC

Accessories

Cell phone Jammer
Directional Antenna*4
Connect cables

According as theoretic

Wireless communication is effectively completed by ensuring adequacy carrier signal density to a certain noise density during communication. A same frequency distortion signal is used to increase the ratio of carrier signal and noise (Nf) for shutting off the communication between the base station and mobile phone.

The output power of jammer is given, the shield radius in the situation of free space is confirmed according to the receiving signal lever from base station and free space attenuation in pass through. The below is given a formula of confirming

Shielding radius and a table of comparison of distance and pass through based on carrier receiving power from base station, output power of jammer as well as gain of antenna:
