350W Up To Six Bands OEM High Power Waterproof Mobile Phone
Signal Prison Jammer
Product Description
Seen from the title of this high power jammer, it can be an OEM signal jammer, you can just tell us your
demand and special specs, then we will customize for you of your need.
Besides, not only it can be customized, but also you can choose your appropriate output power. This up to
350w high power signal jammer supply power range from 300w to 350w, it can meet your diverse need.
What's more, this OEM high power signal jammer had never come into being in the market until now.
Additionally, with great cooling system, it can keep better condition so that can guarantee non-stop working.
What is important is that this jammer can also be customer tailor the frequency bands you want. Welcome
to supply frequency band and need power so that we will customize for you.
Advantages and Features:
1. Each unit can jam up to six frequency bands simultaneously.
2. Continuous operation, even in hot climates, with no time limit.
3. Secure design to avoid sabotage.
4. Adjustable RF power output level.
5. Turn-key design to check the system problem in time.
6. Selection of antennas to provide more flexibility regarding jamming coverage.
7. Special additional housing for all weather protection.
8. Good cooling system via fans design.
9. Heat sink design to make the system more stable.
10. Module design .Easy to change and repair.
| Specification |
| Output Band | Shield band of frequency | RF Output Power | RF OutputdBm |
| CDMA800 | 850-894MHz | 47dBm (50W) | 19dBm/30KHz (min) |
| GSM | 925-960MHZ | 47dBm (50W) | 19dBm/30KHz (min) |
| PCS/DCS | 1805-1990MHz | 47dBm (50W) | 19dBm/30KHz (min) |
| 3G | 2110-2170MHz | 47dBm(50W) | 19dBm/30KHz (min) |
| 4G LTE | 725-770MHz | 47dBm(50W) | 19dBm/30KHz (min) |
| 4G WIMXA | 1700--1800MHz | 47dBm(50W) | 19dBm/30KHz (min) |
| Total Power | 300W |
| Type: | Waterproof |
| Frequency Bands | Up to six bands |
| Power Supply | AC220V/ 110V DC27-28V |
| Power Consumption | 1000W |
| Shielding Radius | 300-600M based on back ground signal strength<=-75dBm |
| Main body Weight | 62.5KG |
| Size | 78*57*32cm |
| Complete set | 92Kg/ Set ( directional antennae)
74Kg /set( Omni antennae) |
| Material | Metal case |
| Packing | Box |
Applications:
Especially for prisons and other large sensitive locations such as military or governmental compounds. It can also use in Oil and Gas Storage Facilities and fields, Security Services, Military Units, Secret Services, Museums, Border Patrol and Drug Enforcement, Customs, etc.
Accessories:
Directional Antennae
Omni directional antennae optional
power supply cable
case key
RF cables
Terms and conditions:
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping./100% advance,paypal,WU, etc. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year :5% of total for each years. |
